40Watts 18:1 Ultra-wide Input 2×1 Inch DC-DC Converter

SKU:

ECB40W18-72S05

High efficiency: Up to 90% efficiency.
High isolation voltage: Provides 3000VAC input/output isolation.
Low standby power consumption: Extremely low no-load input current.
Industrial-grade durability: Operating housing temperature range -40°C to +105°C, and meets EN 50155 railway application standards (shock and vibration resistance) and EN 45545-2 fire and smoke protection standards.
Comprehensive protection: Features over-temperature, over-current, over-voltage, and under-voltage lockout (UVLO) protecti

Output Voltage:

Output Voltage

Part Number	Input Voltage	Output Voltage	Output Current	No load Input Current	Efficiency (%)	I/O Isolation Voltage	Package
EC7AW18-72S05	8.5~160V	5V	2A	6mA	84	3000VAC	DIP24
EC7AW18-72S12	8.5~160V	12V	0.835A	6mA	88	3000VAC	DIP24
EC7AW18-72S15	8.5~160V	15V	0.668A	6mA	88	3000VAC	DIP24
EC7AW18-72D05	8.5~160V	±5V	±1A	6mA	83	3000VAC	DIP24
EC7AW18-72D12	8.5~160V	±12V	±0.416A	6mA	87	3000VAC	DIP24
EC7AW18-72D15	8.5~160V	±15V	±0.333A	6mA	87	3000VAC	DIP24

Additional information

Output Voltage	5V, 12V, 15V, 24V, 48V, 54V
